Super Mini 0.2L Lab Ball Milling Machine for Glove Box Inside Using CE Standard
|Place of Origin:||Hunan, China|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 set|
|Delivery Time:||3-7 working days after getting full payment|
|Payment Terms:||T/T, Western Union, L/C|
|Supply Ability:||200 sets per month|
|Product Name:||Super Mini Planetary Ball Mill||Model No.:||XQM-0.2S|
|Total Volume:||200ml||Max Load Volume:||66ml|
|Rotate Speed:||120-1160 Rpm||Voltage:||220V-50Hz Or 110V-60Hz|
|Power:||0.09KW||Speed Control:||Frequency Control|
lab ball mill,
lab scale ball mill
0.2L Super Mini Laboratory Ball Mill Designed To Be Used Inside Glove Box
Overview of 0.2L Super Mini Laboratory Ball Mill Designed To Be Used Inside Glove Box
0.2S Super mini laboratory ball mill is a necessary equipment used for high-tech materials powder milling, fine grinding, powder mixing, nano powder making, new product development and small batch production. Tencan laboratory ball mill owns advantages and features such as small volume, high efficiency, lower noise and complete functions. Tencan laboratory ball mill is an ideal equipment for R&D institutions, universities, enterprises’ laboratories to get fine powder samples. Tencan planetary ball mill is designed with four working positions and it makes you get four samples (maximum) at one time. you can also use this machine to get powder samples under the vacuum environment if it is equipped with vacuum ball mill jars for grinding.
Super mini planetary ball mill model No.XQM-0.2S is designed to be used inside the glove box under inert gas purification atmosphere with water and oxygen removed.
Working Principle of 0.2L Super Mini Laboratory Ball Mill Designed To Be Used Inside Glove Box
Tencan 0.2L laboratory ball mill has four work positions which can be installed with two or four mill jars on one turntable. When the turntable rotates, the jar axis makes planetary movements at high speed, the balls and materials inside the jars are impacted strongly in high speed movement, and materials are eventually ground into fine powder. Various kinds of different materials can be ground by means of dry or wet grinding method. The smallest granularity of output powder can be reached to 0.1μm or nano scale powder.
Applications of 0.2L Super Mini Laboratory Ball Mill Designed To Be Used Inside Glove Box
Tencan laboratoryball mill is widely used in imany ndustries such as geology, mineral, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, medicine, environmental protection and so on. It is specially most suitable for production fields like electronic ceramics, structural ceramics, magnetic materials, lithium cobalt acid, lithium manganese, catalyst, phosphor, long afterglow phosphor, rare earth polishing powder and electronic glass. Powder, fuel cell, Zinc Oxide varistor, piezoelectric ceramic, nano material, wafer ceramic capacitor, MLCC, thermistor (PTC, NTC), ZnO varistor, dielectric ceramics, alumina ceramics, zirconia ceramics, phosphor, zinc oxide powder, cobalt oxide powder, Ni-Zn ferrite, Mn-Zn ferrite and etc.
Super mini laboratory ball mill model No.XQM-0.2S is a kind of special equipment used for glove box. It can be placed inside the glove box for grinding any sensetive material under vacuum or inert gas protection atmosphere. This model expands greatly application scope for customers and materials research, and grind some materials which can not be milled under normal air atmosphere.
Features of Tencan 0.2L Super Mini Laboratory Ball Mill Designed To Be Used Inside Glove Box
1. Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.
2.Planetary movement principle is adopted in the machine, which has high speed, large energy, high efficiency, small granularity.
3. Four powder samples from different sizes and different materials can be produced at one time.
4. The machine is controlled by frequency converter, you may set ideal rotating speed according to expected experimental result. The converter is equipped with device of under voltage and over-current to protect the motor.
5. The planetary ball mill has functions of timing power off, self-timing forward and reversal rotating. You may select any operation modes of one-way direction, alternation, succession, time setting according to experimental needs, so as to improve efficiency of grinding.
6. Technical features of XQM-2S: small volume, more functions,low center of gravity, stable performance, compact structure, easy operation, reliable safety, lower noise, small loss.
Technical Parameters of 0.2L Super Mini Laboratory Ball Mill Designed To Be Used Inside Glove Box
|0.2L Super Mini Laboratory Ball Mill To Be Used Inside Glove Box|
of Jar Holder
or 220V/50Hz for buyer option
Matching Accessoires of Available Mill Jars for 0.2L Super Mini Laboratory Ball Mill
Besides the planetary ball mill machine, our factory provides all kinds of mill pots,like stainless steel mill pot, zirconia mill pot, alumina mill pot, nylon mill pot, PU mill pot, tungsten mill pot, hard metal mill pot and tempered nylon mill pot etc. Further, we also provide stainless steel mill balls, zirconia mill balls, alumina mill balls, PU mill balls, steel carbon mill balls,tungsten mill balls, etc.
We can also provide all kinds of mill balls like stainless steel balls, zirconia balls, alumina balls, PU balls, steel carbon balls, tungsten balls, agate balls, hard metal balls, silicon nitride balls, high wear resistant steel ball, manganese steel balls, nylon balls, cemented carbide, crystal glass and other special metal materials.
