Laboratory Sieve Shakers 1420Rpm Stainless Steel Vibrating Screeners Diameter 300mm
Product Details:
| Place of Origin: | China |
| Brand Name: | TENCAN |
| Certification: | CE&ISO |
| Model Number: | BZS-300 |
Payment & Shipping Terms:
| Minimum Order Quantity: | One set |
|---|---|
| Price: | negotiable |
| Packaging Details: | Plywood case with foam |
| Delivery Time: | 3-7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 300sets/month |
|
Detail Information |
|||
| Product Name: | Lab Test Sieve Shaker | Model No.: | BZS-300 |
|---|---|---|---|
| Diameter: | 300mm | Screen Size: | 0.008-5.0mm |
| Capacity Per Batch: | Less Than 1kg | Vibrating Frequency: | 1420 Rpm |
| Voltage: | 220V/50Hz/60Hz | Power: | 0.125KW |
| Highlight: | Laboratory Sieve Shakers,Stainless Steel Vibrating Screeners,1420Rpm Vibrating Screeners |
||
Product Description
China Tencan 1420 Rpm Stainless Steel Lab Sieving Shaker Machine,Vibrating Sieve Machine
Technical Parameters of Lab Sieve Shaker
| Items | Unit | Parameters | |
| Standard model(SY) | Deck | 8 | |
| Diameter | mm | φ300φ | |
| granularity | mm | 0.008-5 | |
| Noise | dB | ≤50 | |
| Capacity for each batch | Kg | ≤1 | |
| Amplitude | mm | ≤5 | |
| Motor | Volt | V | 220 |
| Rpm | r/min | 1420 | |
| Power | KW | 0.125 | |
| Overall size | mm | 360×300×736 | |
| Weight | Kg | 25 | |
Lab test sieve shaker introduction
The lab test sieve shaker, which is also referred to as a standard inspection screen, test screen, analysis screen, or simply a standard screen, is a sophisticated fine powder classification tool derived from the standard test screen. It currently stands out as the most efficient solution for overcoming mesh obstruction issues during fine powder sample screening in laboratory contexts. This versatile equipment is extensively employed in laboratories across multiple industries, encompassing pharmaceuticals, metallurgy, chemicals, mineral processing, and food manufacturing.
Applications
The lab test sieve shaker is extensively employed in research and production across diverse industries, such as metallurgy, particulate science, chemicals, pharmaceuticals, building materials, geology, and national defense. Its primary roles involve screening, filtering, and evaluating powders, particles, solid content in liquids, and debris levels. The standard sieve screen, fabricated from either metal woven mesh or punched plate, is commonly customized to meet the buyer's specifications and align with customer requirements regarding mesh size.
Features & Advantages
1. It incorporates a sophisticated integrated circuit control system, providing both functionality and user-friendly operation.
2. A kind of granular material can precisely separate 2-9 particle segments at the same time.
3. It can be used for analysis of fineness and impurity content of slurry.
4. Low noise, light weight, table operation without fixing.
5. Frequency, mode and amplitude of vibration can be adjusted effectively.
Structure Diagram of Lab Test Sieve Shaker
