Laboratory Blender V Shape Dry Powder Mixers Machine 5-500L With Timing Device
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | TENCAN |
| Certification: | CE |
| Model Number: | 1-500L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case+ Foam |
| Delivery Time: | 20-30 working days after getting full payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| Product Name: | V Type Powder Mixing Machine | Material: | 304 Stainless Steel |
|---|---|---|---|
| Specifications: | 5-500L | Packing: | Plywood Case+Foam |
| Voltage: | 220V Or 380V | Type: | Mixing Machine |
| Place Of Origin: | Hunan, China | Certificate: | CE ISO |
| Highlight: | 500L Laboratory Blender,V Shape Laboratory Blender,V Shape Dry Powder Mixers Machine |
||
Product Description
China Tencan 5L-500L V Type Dry Powder Mixing Machine High Efficiency Uniform Mixing Without Dead Corner
Overview
The V-type powder mixing machine is designed for various industries such as pharmaceuticals, food processing, chemicals, metallurgy, and electronics, primarily for blending dry granular materials. It features manual feeding and a closed disc valve discharge system that effectively prevents dust spillage. The machine boasts a unique mixing barrel structure that ensures efficient blending with no dead spots. Constructed from stainless steel, it safeguards against contamination of the mixed materials. Both the interior and exterior of the machine are polished to a high standard. This versatile machine offers uniform mixing and has broad application potential. Additionally, it can be customized with an optional compulsory mixer based on user requirements. It is ideal for mixing smaller powders, blocks, and materials containing a certain percentage of moisture.
Working Principle
The V-type powder mixing machine consists of a container that is welded from two asymmetric cylinders. Through rotary motion, the granule powder undergoes continuous segmentation and merging processes. Material is conveyed from one cylinder to the other, and powder particles stack and redistribute across the powder surface with the slip of powder, resulting in a multiplexing effect.
Features
1. It offers high efficiency in mixing materials with similar or identical granularity and density.
2. It is not easy to crush granule when mixing materials.
3. The machine keeps material particle integrity without extrusion and strong wear.
4. Both the interior and exterior surfaces of the mixing vat are polished to eliminate any dead angles, ensuring there is no risk of cross-contamination between materials.
4. Available materials of mixing vat: carbon steel, stainless steel, nylon, and etc.
5.The machine is furnished with a timing device that allows for the setting of mixing durations, enabling automatic cessation upon completion.
Parameters
| Parameters of V Type Mixing Machine | |||||
| Model No. | Mixing Volume (L) |
Total Volume (L) |
Feed Volume Coefficient |
Power (KW) |
Rotating Speed (rpm) |
| V-5 | 2 | 5 | 0.4 | 0.25 | 50 |
| V-10 | 4 | 10 | 0.4 | 0.25 | 45 |
| V-20 | 8 | 20 | 0.4 | 0.37 | 32 |
| V-50 | 20 | 50 | 0.4 | 0.75 | 32 |
| V-100 | 40 | 100 | 0.4 | 1.5 | 30 |
| V-200 | 80 | 200 | 0.4 | 3 | 24 |
| V-300 | 120 | 300 | 0.4 | 4 | 20 |
| V-500 | 200 | 500 | 0.4 | 7.5 | 12 |
