High Precision Planetary Ball Mill Achieve Minimum 0.1μM Output Granularity Size
Product Details:
Place of Origin: | Hunan China |
Brand Name: | TENCAN |
Certification: | ISO CE |
Model Number: | XQM-0.4A |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 set |
---|---|
Price: | negotiable |
Packaging Details: | Carton & Foam |
Delivery Time: | 7-15 days |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 100Set/Sets per Week |
Detail Information |
|||
Production Ability: | 0.01-0.132kg/h | Product Name: | Planetary Ball Mill |
---|---|---|---|
Voltage: | 220V | Key Word: | Lab Grinding Mill |
Output: | Minimum 0.1μm | Working Model: | 2 Or 4 Pots One Time |
Application: | Grinding & Mixing | Power: | 0.25KW |
High Light: | High Precision Planetary Ball Mill,Powder Mixing Planetary Ball Mill,Nano Powder Planetary Milling Machine |
Product Description
High-Precision Milling Ball Mill Achieve Minimum 0.1μm Output Granularity Size
Product Description:
Laboratory Planetary Ball Mill Machine
The laboratory planetary ball mill machine is a necessary device for high-tech materials milling, fine grinding, powder mixing, nano powder making, new product development and small batch production. Tencan provides a planetary ball mill that offers advantages such as small volume, high efficiency, low noise, and complete functions; allowing for use in R&D institutions, universities, and enterprise laboratories to get fine powder samples. The design of the Tencan planetary ball mill allows a maximum of four samples to be taken at the same time, with the added feature of being able to also use the machine in a vacuum environment if it is equipped with vacuum ball mill jars for grinding. With its many features and functions, the Tencan planetary ball mill machine is a must-have for high-tech material milling.
Features:
- Product Name: Planetary Ball Mill
- Voltage: 220V
- Key Word: Lab Grinding Mill
- Application: Gringding & Mixing
- Feeding Size: ≤10mm
- Max Production Capacity: 0.132L
- Device: Planetary Ball Milling Device, High-Energy Ball Mill, Planetary Milling Ball Mill
Technical Parameters:
Parameter | Value |
---|---|
Product Name | Planetary Ball Mill |
Production Ability | 0.01-0.132kg/h |
Working Model | 2 or 4 Pots One Time |
Output | Minimum 0.1μm |
Power | 0.25KW |
Voltage | 220V |
Application | Grinding & Mixing |
Rotate Speed | 90-870rpm |
Max Production Capacity | 0.132L |
Package | Cartoon With Foam |
Applications:
The laboratory planetary ball mill machine is a highly versatile tool used in a wide variety of industries. It has been utilized in industries such as geology, mineralogy, metallurgy, electronics, building materials, ceramics, chemical engineering, light industry, medicine, and environmental protection, just to name a few.
It has been found to be especially effective for electronic ceramics, structural ceramics, magnetic materials, lithium cobalt acid, lithium manganese, catalysts, phosphors, long afterglow phosphors, rare earth polishing powders, and electronic glasses. In addition, it is widely applicable to the production of fuel cells, zinc oxide varistors, piezoelectric ceramics, nano-materials, wafer ceramic capacitors, MLCC, thermistors (PTC, NTC), ZnO varistors, dielectric ceramics, alumina ceramics, zirconia ceramics, phosphors, zinc oxide powders, cobalt oxide powders, Ni-Zn ferrites, and Mn-Zn ferrites.
Customization:
Brand Name: TENCAN
Model Number: XQM-0.4A
Place of Origin: Hunan China
Certification: ISO CE
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Carton or plywood & Foam
Delivery Time: 7-15 days
Payment Terms: T/T
Supply Ability: 100Set/Sets per Week
Feeding Size: ≤10mm
Output: Minimum 0.1μm
Application: Grinding & Mixing
Package: Plywood Case With Foam
Max Production Capacity: 0.132L
- Ball Milling Machine
- Planetary Ball Milling Device
- Grinding Planetary Ball Mill
FAQ:
-
1. Are you manufacturer or trade company?
We are one of leading manufacturers in China, which focuses on designing, manufacturing and selling all kinds of powder grinding equipment including planetary ball mills, roll ball mills, stir ball mills, crushers, mixers and sieve shakers as well as accessories matched with machines.
2. What is your delivery time if I place an order?
We often have a great deal of regular machine models and accessories in stock available. If you want to order our regular items, it takes about 1-3 working days to finish packing and inspection, Generally speaking we can make shipment of regular order from our warehouse within 3-7 working days after payment is received.
3. What questions about requirements are required to provide to us if you inquiry about ball mills?
Answers:
* What material is needed to be grind? By wet or dry method?
* How many liters of material are required to be ground per batch?
* What is feed size (mm) of starting materials?
* What final particle size (μm or nm or meshes) is required by grinding?
* Is material allowed with metal impurity contamination while grinding?4. Can you provide testing service of grinding experiment before we place an order?
Yes. sample grinding experiment is available for any customer who is willing to send materials to us, and grinding experiment of sample is always free of charge.
Delivery address of material sample:
Changsha Tianchuang Powder Technology Co., Ltd
Room 804, 2nd Building, No.68 Luositang Road, Changsha Economic and Technological Development Zone, Changsha, Hunan, China 410100
Contact Name: Aivin Ai Mobile Phone: +86 13548659522
5. What’s your warranty?
One-year warranty period is provided. If any problem while you are using the machine, you can send Email to: service@lab-mills.com for after-sale services.
6. What is MOQ (Minimum Order Quantity) of one order?
One set of machine or one piece of accessories (like ball mill jar and balls) are acceptable.
