Small Lab Planetary Ball Mill Machine , Enchtop Ball Mill With Output 0.1 Micron
Product Details:
Place of Origin: | Hunan, China |
Brand Name: | TENCAN |
Certification: | CE ISO |
Model Number: | XQM-0.4A |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiable |
Packaging Details: | Carton+Foam |
Delivery Time: | 3-7 work days |
Payment Terms: | T/T, Western Union, MoneyGram |
Supply Ability: | 220 sets per month |
Detail Information |
|||
Product Name: | Mini Size Planetary Ball Mill | Model No.: | XQM-0.4A |
---|---|---|---|
Total Volume: | 400ml | Max Capacity: | 132KW |
Rotate Speed: | 90-870 Rpm | Speed Control: | Frequency Control |
Voltage: | 220V-50Hz Or 110V-60Hz | Power: | 0.25KW |
Highlight: | planetary mill,planetary milling machine |
Product Description
XQM-0.4A Best price Small Lab Planetary Ball Mill with output 0.1 micron
Application Area of Best price Small Lab Planetary Ball Mill with output 0.1 micron:
Features of Best price Small Lab Planetary Ball Mill with output 0.1 micron:
1. Elegant design, easy to operate
2. Ideal for wet or dry grinding application
3. Multiple grinding modes to choose
4. High uniformity and excellent repeatability
5. Four samples with different sizes and materials in one experiment
6. Large range of materials available for grinding media
7. Automatic and programmable control with LED display
8. Fast rotational speed, high efficiency and fine granularity
9. Programmable interval and pause times
10. Cooling of the grinding chamber with a built-in fan for long grinding times
Technical Datas of Best price Small Lab Planetary Ball Mill with output 0.1 micron:
Working Principle | impact and friction force |
Item No. | XQM-0.4A-110V 60Hz |
Compatible Non Vacuum Grinding Jars | (50ml~100ml) * 4 |
Compatible Vacuum Grinding Jars | 50ml *4, 50ml grinding jars only for vacuum |
Operation Mode | 2 or 4 grinding jars working simultaneously |
Feeding Granularity | Soil materials < 10mm, others materials < 3mm |
Discharging Granularity | down to 0.1μm |
Sample Type | hard, medium-hard, soft, fibrous, brittle, moist |
Rotational Speed of Grinding Jar | 1100rpm |
Rotational Speed Ratio (planetary disk/jar) | 1 : -2 |
Drive Mode | gear drive and belt drive |
Speed Control | stepless speed regulation |
Electrical Details | 110VAC, 60Hz, 0.25KW, with an external transformer |
Max Continuous Grinding Time (full-load) | 72hours |
Weight (Net /Gross) | 32KG /45KG |
Dimension (L*W*H) | 500*300*340mm |
Package (L*W*H) | 600*370*470mm |
Remarks:
Please note: for this TENCAN Ball mill, you require two or four grinding jars of your choice and the corresponding number of grinding balls. The grinding jar material must be harder than the material to be ground. In normal cases, grinding jars and balls of the same material are used. To shorten the grinding time, larger or heavier grinding jars and grinding balls with a higher density can be used.
Technical Parameters
Main Parameters of 0.4L 110 - 220v Mini Planetary Ball Mill | |||||
Model | Power(KW) | Voltage | Dimension(mm) | Revolution Speed (rpm) |
RotationSpeed (rpm) |
XQM-0.4A | 0.25 | 220V-50Hz | 530*300*340 | 45-435 | 90-870 |
Accessories of Mill Jars & Balls
Available Mill Jars:
304 stainless steel mill jar, 316 stainless steel mill jar, tungsten carbide mill jar, agate mill jar, alumina ceramic mill jar(also called corundum mill jar), zirconia mill jar, nylon mill jar, polyurethane mill jar, mill jar (PTFE), and etc.
Available Mill Balls:
304 stainless steel mill balls, 316 stainless steel mill balls, tungsten carbide mill balls, agate mill balls, alumina balls, zirconia mill balls, and etc.
