Double Planetary Discs Dual Planetary Grinder 1120 RPM High Performance

Double Planetary Discs Dual Planetary Grinder 1120 RPM High Performance

Product Details:

Place of Origin: Hunan, China
Brand Name: TENCAN
Certification: CE ISO
Model Number: SXQM-2

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywood Case+Foam
Delivery Time: 20 working days
Payment Terms: T/T, Western Union
Supply Ability: 100 sets per month
Get Best Price Contact Now

Detail Information

Product Name: Dual Planetary Ball Mil Model No.: SXQM-2
Total Volume: 2L Max Capacity: 0.66L
Rotate Speed: 140-1120 RPM Speed Control: Frequency Control
Voltage: 220V-50Hz Or 110V-60Hz Power: 1.5KW
High Light:

planetary mill


planetary milling machine

Product Description

0.4-6L Dual Planetary Ball Mill with Double Planetary Discs And High Speed 1120 RPM More Quicker & Finer for Grinding




Dual planetary ball mill is a necessary device used for high-tech materials milling, fine grinding, powder mixing, nano powder making, new product development and small batch production. Tencan planetary ball mill owns advantages and features such as small volume, high efficiency, low noise and complete functions. Tencan planetary ball mill is an ideal equipment for R&D institutions, universities, enterprises’ laboratories to get fine powder samples. Tencan planetary ball mill is designed with four working positions and it makes you get four samples (maximum) at one time. you can also use this machine to get powder samples under the vacuum environment if it is equipped with vacuum ball mill jars for grinding.

Dual planetary ball mill realizes movement of the small planetary disk driven by the large planetary disk, the rotation radius and the rotation speed of the mill jars are magnified compared to the normal planetary ball mill models. The centrifugal force of the grinding balls is doubled, the impact, shear and friction between the grinding balls increase significantly, the grinding effect and the grinding efficiency are enhanced greatly, and some materials can be ground into nano scale. Dual planetary ball mill is a typical kind of high efficiency and high energy ball mill.


Working Principle


Dual planetary ball mill is designed to have two planetary disks that make rotation movement installed on a base turntable which makes revolution movement. Another two smaller turntables are installed on each larger disk respectively; there are two mill jars on each smaller turntable. The machine has totally four mill jars installed on the smaller turntables. When the base turntable rotates, the tank roller makes planetary movements. The balls and samples inside the mill jars are ground and mixed under high speed movement.





Dual planetary ball mill is a necessary grinding equipment for producing high-tech materials in laboratory, mixing, fine grinding and small batch production. The machine has advantages such as beautiful appearance, compact structure, convenient operation, high working efficiency and fine grind uniformity. It is a preferred equipment for scientific research, teaching, experiment and production. And is widely used in industries of electronics, magnetism, medicine, ceramics, geology, minerals, metallurgy, building materials, chemical industry, light industry, beauty, environmental protection and etc.






1. The mill jar makes two planetary movement, It enjoys high efficiency and small particle size under the high frequency percussion, linear collision force, friction force.( First in China)
2. Four different samples can be got at one time. It is convenient for the technologist to do the research and develop the new material.
3. Feed Granularity of Materials: Soil material ≤10mm, other materials ≤3mm.
4. Wet or dry grinding method. Minimum Granularity of powder amounts to 0.06 μm.
5. Frequency controlled, you can set the speed as per experiment effect.
6. Large turn disc revolution: 50-400rpm.
Small turn disc revolution: 100-800rpm.
Large planetary axis rotation: 100-800rpm.
Mill pot rotation: 200-1600rpm.
7. The planetary ball mill has timing power off, self-timing forward and inversion function. It can raise the efficiency by choosing one-way, alternately, continuously, time-setting operation.
8. Motor power: 0.4L, 2L, 4L: 0.75KW, 220V, 50Hz; 16L, 20L: 5.5KW, 380V, 50Hz.
9. Our planetary ball mill is functional which has low bary center, stable performance, compact structure, easy operation, reliable safety, low noise, and low wastage.




Dual planetary ball mill is an ideal facility to acquire samples for research institutes , universities as well as enterprise laboratories (can acquire four samples in one experiment). If mated with vacuum ball milling tanks, it can grind samples in vacuum status. The product is extensively applied to in the fields of Geology, Mining, Metallurgy, Electronics, Construction Material, Ceramics, Chemical Engineering, Light Industry Medicine, Environmental Protection etc.
A wide range of powder can be ground by our planetary ball mill with different mill jars and balls, such as ore powder, fluorescent powder, glass powder, pigment powder and so on. Following are some powder samples for your reference.





Technical Parameters


Main Parameters of Dual Planetary Ball Mill
Model No. Power
Revolution Speed
Rotation Speed
Total Timing
Alternating Run
Time of Forward &
Reversal Rotation
SXQM-0.4 1.5 220V-50Hz 1150*800*760 70-560 140-1120 1-9999 1-999
SXQM-1 1.5 220V-50Hz 1150*800*760 70-560 140-1120 1-9999 1-999
SXQM-2 1.5 220V-50Hz 1150*800*760 70-560 140-1120 1-9999 1-999
SXQM-4 1.5 220V-50Hz 1150*800*760 70-560 140-1120 1-9999 1-999
SXQM-6 1.5 220V-50Hz 1150*800*760 70-560 140-1120 1-9999 1-999
Feeding Size: Soil material≤10mm, other materials≤3mm
Output Granularity: Minimum 0.1 μm
Optional Models of Speed Control: Frequency converter and automatic timing control
Materials of Jar: Stainless steel, agate, nylon, corundum, zirconia, etc.



Accessories of Mill Jars & Mill Balls


As a professional manufacturer of planetary ball mill, we not only supply various kinds of planetary ball mills, but also provide all kinds of accessories of mill jars and mill balls in full sizes.

Available mill jars: 304 or 316L stainless steel mill jars, agate mill jars, , Alumina  ceramic mill jars (corundum ) zirconia mill jars, silicon nitride mill jars, nylon mill jars, PU mill jars, tungsten carbide mill jars, PTFE mill jars, and etc.


Double Planetary Discs Dual Planetary Grinder 1120 RPM High Performance 0


We calso provide all kinds of mill balls like stainless steel balls, zirconia balls, alumina balls, tungsten balls, agate balls,


TENCAN is the leading manufacturer who engages in design & produce all kinds of lab ball mills and other powder equipment in China. Our factory was established in 2006, and our products have been exported to more than 60 countries throughout the world.

Main Product range of TENCAN:
1. Planetary Ball Mill-- for grinding various materials to nanoscale size(<0.1 μm);
2. Lab Roll Ball Mill-- for grinding various materials to micron powder (13-48 μm);
3. Lab crusher-- for primary crushing material samples to suitable size(1-30mm);
4. Powder mixer machine from 5L to 5000L;V type mixer, 3D mixer, Double cone mixer etc.;
5. Glove box series including transparent glove box, stainless steel vacuum glove box and glove box with inert gas purification system for different experimenting conditions.
6. Spare parts for ball mill equipment, such as grinding jars, grinding balls made of various materials and other accessories.
