Product Details:

Place of Origin: Hunan, China
Brand Name: HENGNUO
Model Number: 4-20N/4-20R

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: Carton+Foam
Delivery Time: 7-10 working days after receiving full payment
Payment Terms: T/T
Supply Ability: 500 sets per month
Get Best Price Contact Now

Detail Information

Product Name: High & Low Speed Universal Centrifuge Model No.: 4-20N/4-20R
Max Rotation Speed: 21000 Rpm Timing Range: 1min~99min59s
High Light:

21000 Rpm Universal Centrifuge

,

1min Universal Centrifuge

,

800W Universal Centrifuge

Product Description

High and Low Speed Universal Centrifuge



4-20N (Normal Temperature)/4-20R (Refrigerated)



Product Introduction



1. High and low speed universal centrifuge is equipped with a variety of rotors and tube racks, which has centrifugation with large capacity and



high speed in multiple utilization.



2. Using New type composite material for angle rotor, the instrument has advantages of super light, high strength, slow heat conduction, strong



corrosion resistance, fast speed up and down.



3. Microcomputer control, AC variable frequency motor drive, stable and quiet operation.



4. Large LCD displays parameters such as speed, centrifugal force, temperature and time in real time, and you can change parameters at any



time during operation without shutdown.



5. 10 gears for speed acceleration and deceleration control, free stop time of 9 gears can be up to more than 540s, which meets requirements of



special separated articles



6. It is displayed in second when the countdown time is less than one minute.



7. Electronic door lock, all-steel inner cavity protection cover, protection set for over speed and over temperature, ensure safety of people and



instrument.



8. Suitable for separating and purifying of radioimmunity, biochemistry, bio-pharmaceuticals, and blood products.



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 0   High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 1



Technical Parameters





Model No. 4-20N(Normal Temperature) 4-20R(Refrigerated)
Max Rotation Speed 21000rpm
Max Relative Centrifugal Force 29200*g
Max Capacity 4*750ml
Timing Range 1min~99min59s
Total Noise < 65dB(A)
Total Power 800W 1500W
Diameter of Centrifugal Cavity 4200mm 420mm
Compressor Unit / 进口压缩机组无氟制冷
Temperature Setting Range / -20℃~40℃
Temperature Accuracy / ±1.0℃
Power Supply AC 220±22V 50Hz 10A AC 220±22V 50Hz 16A

Outline Dimensions

(L*W*H)

545×468×350(mm) 640×730×430(mm)
Net Weight 50kg 95kg



Applicable Rotors





High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 2



#1 Angle Rotor

Single tube capacity: 1.5ml

Total capacity: 12*1.5ml

Max speed: 21000rpm

Max relative centrifugal force:29200*g

High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 3

#2 Angle Rotor

Single tube capacity:

5ml

Total capacity: 10*5ml

Max capacity:16500rpm

Max relative centrifugal force:18365*g





High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 4



#3 Angle Rotor



Single tube capacity: 1.5ml

Total capacity: 24*1.5ml

Max speed: 16500rpm

Max. RCF: 24890*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 5



#4 Angle Rotor

Single tube capacity:

10ml

Total capacity: 12*10ml

Max speed: 15000rpm

Max. RCF: 23120*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 6

#5 Angle Rotor

Single tube capacity: 15ml

Total capacity: 12*15ml

Max speed: 12000rpm

Max. RCF: 15455*g

High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 7

#6 Angle Rotor

Single tube capacity: 1.5ml

Total capacity: 36*1.5ml

Max speed: 15000rpm

Max. RCF: 20753*g





High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 8

#7 Angle Rotor

Single tube capacity: 50ml

Total capacity: 6*50ml

Max speed: 12000rpm

Max. RCF: 15805*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 9

#8 Angle Rotor

Single tube capacity:

50ml cone

Total capacity: 6*50ml cone

Max speed: 11000rpm

Max. RCF: 13274*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 10

#9 Angle Rotor

Single tube capacity: 100ml

Total capacity: 4*100ml

Max speed: 11000rpm

Max. RCF: 13000*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 11



#10 PCR Rotor

Single tube capacity: 0.2ml PCR tube

Total capacity: 4*8*0.2ml PCR tube

Max speed: 15000rpm

Max. RCF: 17357*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 12

#11 Angle Rotor

Single tube capacity: 0.25-1ml blood capillary

Total capacity: 24*(0.25-1ml)

Max speed: 12000rpm

Max. RCF: 10142*g

High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 13

#12 Angle Rotor

Single tube capacity: 1.5ml

Total capacity: 48*1.5ml

Max speed: 12000rpm

Max. RCF: 14890*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 14

#13 Angle Rotor

Single tube capacity: 250ml

Total capacity: 4*250ml

Max speed: 10000rpm

Max. RCF:

13000*g (Only 4-20R)





High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 15

#14 Horizontal Rotor

Single tube capacity:750ml

Total capacity: 4*750ml

Max speed: 4000rpm

Max. RCF: 3580*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 16

#15 Enzyme plate rotor



Single tube capacity: 96/384

hole plate

Total capacity:

4*2*96 hole plate

Max speed: 4000rpm

Max. RCF: 3550*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 17

#16 Horizontal Rotor

Single tube capacity: 500ml

Total capacity: 4*500ml

Max speed: 4000rpm

Max. RCF: 3580*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 18



#17 Horizontal Rotor

Single tube capacity: 5ml/7ml

Total capacity: 96*5ml

Max. Speed: 4000rpm

Max. RCF: 3500*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 19

#18 Horizontal uncap Rotor

Single tube capacity:2ml/5ml/7ml

Blood collection tube

Total capacity: 96*5ml

Max speed: 4000rpm

Max. RCF: 3580*g

High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 20



#19 Horizontal Rotor

Single tube capacity: 250ml

Total capacity: 6*250ml

Max speed: 4000rpm

Max. RCF: 3500*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 21



#20 Horizontal Rotor

Single tube capacity: 250ml

Total capacity: 4*250ml

Max speed: 4000rpm

Max. RCF: 3500*g

High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 22



#21 Horizontal Rotor

Single tube capacity: 10ml/15ml

Total capacity: 32*10ml/15ml

Max speed: 4000rpm

Max. RCF: 2810*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 23



#22 Horizontal Rotor

Single tube capacity: 50ml/100ml

Total capacity: 8*50ml/100ml

Max speed: 4000rpm

Max. RCF: 2810*g



   High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 24

#23 Horizontal Rotor

Single tube capacity: 5ml/7ml

Total capacity: 48/64/72*5ml

Max speed: 4000rpm

Max. RCF: 2810*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 25

#24 Horizontal Rotor

Single tube capacity: 50ml/100ml

Total capacity: 4*50ml/100ml

Max speed: 5000rpm

Max. RCF: 4390*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 26

#25 Enzyme plate rotor

Single capacity: 96/384 hole plate

Total capacity: 2*2*96 hole plate

Max speed: 4000rpm

Max. RCF: 2300*g

High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 27



#26 PRP Rotor

Single tube capacity: 50ml injector

Total capacity: 4*50ml

10ml/20ml Adapter optional

Max speed: 5000rpm

Max. RCF: 4390*g



High Low Speed 21000 Rpm Universal Centrifuge 4-20N / 4-20R 28



#27 Uncap Rotor

Single tube capacity: 2ml/5ml/7ml

Blood collection tube

(only 2ml uncap)

Total capacity: 48*5ml

Max speed: 4000rpm

Max. RCF: 3500*g
