Tungsten Carbide Planetary Ball Mill Jar High Hardness Metal Powder Grinding Use
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | TENCAN |
| Certification: | CE ISO |
| Model Number: | 50ml-2000ml |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1000 kgs per month |
|
Detail Information |
|||
| Product Name: | Tungsten Carbide Planetary Ball Mill Jar | Sizes: | 50ml-2000ml |
|---|---|---|---|
| Material: | Tungsten Carbide | Hardness: | More Than 9.0 Mohs |
| Brand: | TENCAN | Place Of Origin: | Hunan, China |
| Usage: | Accessories For Planetary Ball Mill | Certification: | ISO CE |
| High Light: | grinding mill jars,ball mill tank |
||
Product Description
50ML-1000ML Tungsten Carbide Planetary Ball Mill Jar in High Hardness For Metal Powder Grinding
Overview
Tungsten carbide ball mill jar is made from hard compounds of refractory metal and bounding metal by means of powder metallurgy process. It has advantages of high hardness, wearing resistance, high strength, good toughness, heat resistance and corrosion of 500 centigrade due to its special features of heat resistance, high hardness and good wearing resistance.
Applications:
Tungsten carbide ball mill jar is used as grinding jar of planetary ball mill matched with tungsten carbide balls, which is suitable for grinding materials in high hardness such as hard alloy powder, diamond powder, and silicon carbide powder.
Features
1. High temperature resistance: The Maximum temperature which it bears can be amounted to 1000 centigrade.
2. High wearing resistance even at temperature of 500 centigrade.
3. High hardness: super high hardness is the key factor of tungsten carbide mill jar.
4. Strong toughness: not only it owns high hardness, but also good toughness.
Parameters
| Parameters of Tungsten Carbide Planetary Ball Mill Jars | |||
| Specifications | External Diameter (mm) |
Inner Diameter (mm) |
Height (mm) |
| 50ml | 55 | 38 | 38 |
| 100ml | 65 | 50 | 50 |
| 250ml | 92 | 74 | 74 |
| 500ml | 100 | 84 | 84 |
| 1000ml | 128 | 108 | 108 |
| Recommendation For Matching Solutions About Mill Jars & Materials | |
| Categories of Materials | Recommended Mill Jars |
| Soil and other Materials which are not allowed with any impurity | Agate mill jar |
| Metal & nonmetal materials which are not allowed with any impurity | Zirconia mill jar |
| High hardness materials like diamond, tungsten carbide | Tungsten carbide mill jar |
| Strong add & alkali materials or other materials at high temperature | PTFE mill jar |
| Iron ore materials with lower impurity sensitivity | 304 Stainless steel mill jar |
| Pigment or other materials with later process under high temperature | Nylon mill jar |
| Aluminum materials like ceramic glaze | Corundum mill jar |
| Electronic materials like lithium battery | Polyurethane mill jar |
| Easily oxidized materials or some special materials which need to be protected under special atmosphere. | Vacuum mill jar |
| Matching Solutions for Mill Jars & Balls | |||||
| Items | Agate Balls | Alumina Balls | Stainless Steel Balls | Zirconia Balls | Tungsten Carbide Balls |
| Agate Mill jar | √ | ||||
| Corundum Mill Jar | ▲ | √ | ▲ | ||
| Stainless Steel Mill Jar | √ | ||||
| Zirconia Mill Jar | ▲ | √ | |||
| Nylon Mill Jar | ▲ | √ | |||
| PTFE Mill Jar | √ | ▲ | |||
| Polyurethane Mill Jar | √ | ▲ | |||
| Tungsten Carbide Mill Jar | ▲ | √ | |||
| √ means: most suitable ▲ means: suitable | |||||
