Nano Grinding Full Direction Ball Mill Feeding Size Less Than 10mm Output Down To 0.1μM
Product Details:
| Place of Origin: | Changsha Hunan China |
| Brand Name: | TENCAN |
| Certification: | ISO CE |
| Model Number: | QXQM-4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | Carton & Foam |
| Delivery Time: | 7-15 days |
| Payment Terms: | T/T, Western union，L/C |
| Supply Ability: | 200 Sets per Month |
|
Detail Information |
|||
| Working Model: | 2 Or 4 Pots One Time | Rotate Speed: | 70-670rpm |
|---|---|---|---|
| Key Word: | Laboratory All-dimensional Ball Mill | Power: | 0.75KW |
| Warranty: | 1 Year | Voltage: | 220V Or 110V |
| Production Ability: | 0.1-1.32kg/h | Output: | Down To 0.1μm |
| High Light: | Full Direction Ball Mill,Nano Grinding Direction Ball Mill,Full Direction Planetary Ball Mill |
||
Product Description
Nano Grinding Full-Direction Ball Mill Feeding Size Less Than 10mm Output Down To 0.1μm
Product Description:
Full-directional Laboratory Ball Mill is an essential tool for the milling of high-tech materials, finely grinding, powder mixing, nano powder manufacturing, and new product development and small batch production. Tencan planetary ball mill offers many advantages, such as small volume, high efficiency, low noise, and complete features. It is the ideal device for R&D institutions, universities, and corporate laboratories to obtain fine powder samples.
This machine is equipped with four working positions; therefore four samples (at the most) can be obtained at one time. It is possible to draw powder samples in a vacuum environment if a planetary ball mill with vacuum ball mill jars is used.
The full-directional Ball Mill usually has four ball grinding positions placed on one disc. When the turnover disc rotates, the mill pots rotate on their axes as well as make 360° rotation. The balls inside the tanks will blend and crush the samples at high speed.
The product can mix and grind various types and sizes of material with dry or wet technique. The least amount of granulated material can be as small as 0.1 micrometers. It is predominantly used in the fields of Geology, Mining, Metallurgy, Electronics, Construction Materials, Ceramics, Chemical Engineering, Light Industry, Medicine and Environmental Protection.
Features:
- Product Name: Planetary Ball Mill
- Voltage: 220V Or 110V
- Production ability: 0.1-1.32kg/h
- Feeding Size: Less Than 10mm
- Output: Down To 0.1μm
- Transmission mode: Gear Rotation
- Ball Mill Grinding Machine: Yes
- Ball Mill Grinder: Yes
- Grinding Planetary Ball Mill: Yes
Technical Parameters:
| Parameter | Value |
|---|---|
| Production ability | 0.1-1.32kg/h |
| Output | Down To 0.1μm |
| Max Production Capacity | 1.32L |
| Rotate Speed | 70-670rpm |
| Key Word | Laboratory All-dimensional Ball Mill |
| Power | 0.75KW |
| Feeding Size | Less Than 10mm |
| Product Name | Full-directional Planetary Ball Mill |
| Voltage | 220V Or 110V |
| Warranty | 1 Year |
Applications:
The TENCAN QXQM-4 Planetary Ball Mill is a high-energy ball mill that is designed to grind various materials, from soft to extremely hard. It is certified by ISO and CE, and comes with a minimum order quantity of one set. Furthermore, it is packaged in a sturdy carton and foam for added protection. The delivery time for this product is 7-15 days, and payment options include T/T, Western Union and L/C. This high-energy ball mill has a production ability of 0.1-1.32kg/h and a warranty of one year. It has a working model of two or four pots one time, and a voltage of 220V or 110V. It is supplied with 200 sets per month, and the price is negotiable. This product is a great choice for those looking for a high-quality, high-energy ball mill.
Customization:
Brand Name: TENCAN
Model Number: QXQM-4
Place of Origin: Changsha Hunan China
Certification: ISO CE
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Carton & Foam
Delivery Time: 7-15 days
Payment Terms: T/T, Western union,L/C
Supply Ability: 200 Sets per Month
Power: 0.75KW
Voltage: 220V Or 110V
Rotate Speed: 70-670rpm
Production ability: 0.1-1.32kg/h
Key Word: Laboratory All-dimensional Ball Milling Machine, Ball Milling Machine, Grinding Planetary Ball Mill
FAQ:
Q1: What is TENCAN Planetary Ball Mill?
A1: TENCAN Planetary Ball Mill is a compact and easy-to-use laboratory planetary ball mill for mixing, homogenizing, fine grinding, mechanical alloying, cell disruption, small sample preparing, new product development and small volume high-tech material production.
Q2: What is the Model Number of TENCAN Planetary Ball Mill?
A2: The Model Number of TENCAN Planetary Ball Mill is QXQM-4.
Q3: Where is TENCAN Planetary Ball Mill made?
A3: TENCAN Planetary Ball Mill is made in Changsha Hunan, China.
Q4: Does TENCAN Planetary Ball Mill have any certifications?
A4: Yes, TENCAN Planetary Ball Mill has ISO CE certifications.
Q5: What is the minimum order quantity of TENCAN Planetary Ball Mill?
A5: The minimum order quantity of TENCAN Planetary Ball Mill is 1 set.
